Controller | Intel Chip |
Baffle Height | Full height |
Power Consumption | 6.0W |
System Support | Windows 7/8/8.1/10/11 |
Windows Server 2008 R2/2012 R2/2016 R2/2019 R2/2022 R2;; | |
Linux Stable Kernel version 2.6.x / 3.x/4.x or later; | |
Linux CentOS/RHEL 6.x / 7.x or later; | |
Ubuntu 14.x/15.x/16.x or later; | |
VMware ESX/ESXi 4.x/5.x/6.x or later | |
Bus Type | PCIe v2.1 x4, compatible with x8, x16 |
Data rate supported per port | 10/100/1000MbE |
Connector | 4*8-Pin RJ45 |
Protocol Support | IEEE 802.3ab 1000BASE-T Gigabit Ethernet IEEE 802.3u 100BASE-TX Fast Ethernet IEEE 802.3z IEEE 802.1Q VLANs IEEE 802.3x IEEE 1588 IEEE 802.3az - Energy Efficient Ethernet (EEE) |
PXE | No |
DPDK | Yes |
Wol | No |
iSCSI | No |
Jumbo Frames | Yes |
FCoE | No |
Operating Temperature | 0 ℃ to 55 ℃ (32 ℉ to 131 ℉) |
Storage Temperature | -40 ℃ to 70 ℃ (-40 ℉ to 158 ℉) |
Storage Humidity | Maximum: 90% non-condensing relative humidity at 35 ℃ |
Size(mm) | 147.2*120*21 |
Weight(g) | * |
LED Indicators | 1000Mbps: Yellow Link + Green Blink |
| 100Mbps/10Mbps: Green Blink |
P/N | Description |
LRES3004PT-A | PCIe x4 Quad-port Gigabit Ethernet Network Adapter (Intel Chip Based) |
