LRES1059PT is a PCIe x1 2.5G Single-port Desktop Adapter developed by Linkreal Co., Ltd. based on Intel master control scheme. This adapter provides better network performance than gigabit network for high quality network requirements such as home network, home storage, online games and other applications. Solve in do not need to link but the use of gigabit can not be satisfied with the occasion.
By using the card to add a 2.5G speed network link port on the computer, to achieve faster than gigabit network speed, better cost-effective network card; It can be widely used in household storage, industrial computer, embedded computer, single board computer, digital multimedia and other applications.
Model | LRES1059PT | |
Controller | Intel KTI226V | |
Cable medium | Copper | |
Fiber Type | NBase-T | |
Bracket Height | Low Profile & Full Height | |
Power (max) | 2.0W | |
Bus Interface | PCIe v3.1 (5.0GT/s) x1; compatible with x4, x8, x16 | |
Data rate per port | 10/100/1000/2500Mbps | |
Connector | 1*RJ45 | |
Power Supply | PCIe | |
Operating System Support | * Windows 10/11 * Deepin 20.9 * Ubuntu 20.04.1/22.04.2 | * openKylin 0.7.5 * Mikrotik * ikuai |
PXE | No | |
WoL | Yes | |
Jumbo Frames | Yes | |
SR-IOV | No | |
IEEE 1588 | Yes | |
UEFI | Yes | |
Jumbo Frame(max) | 9.2KB | |
Protocol Support | IEEE 802.1bz 2500BASE-T Ethernet IEEE 802.3ab 1000BASE-T Gigabit Ethernet IEEE 802.3u 100BASE-TX Fast Ethernet IEEE 802.3x | |
10Mbps/100Mbps | Connection Status | Green Link |
Transfer status | Green Blink | |
1Gbps | Connection Status | Green Link + Orange Link |
Transfer status | Green Blink + Orange Link | |
2.5Gbps | Connection Status | Green Link + Green Link |
Transfer status | Green Blink + Green Link |
Operating Temperature | 0℃ to 70℃ (-32 ℉ to 158 ℉) |
Storage Temperature | -40 ℃ to 85 ℃ (-40 ℉ to 185 ℉) |
Storage Humidity | Maximum: 90% non-condensing relative humidity at 35 ℃ |
Certification | FCC, CE, RoHS |
