LREC9054PF-4SFP is a 4-port PCI express x4 server adapter card independently developed by Shenzhen Liangrui Electronics Co., Ltd. based on Intel master control scheme. PCI Express is equipped with dedicated I/O bandwidth to deliver superior performance without taking up bus bandwidth for use in megabit Ethernet connections on fiber optic networks. 4 onboard SFP slots can be compatible with a variety of 100 MB SFP modules, users can choose fiber optic modules according to the actual transmission distance, without changing the network card.
Controller | Intel Chip |
Baffle Height | Full-height & half-height bracket |
Power Consumption | 3.48W |
System Support | Windows XP/Vista/7/8/8.1/10 |
Windows Server 2003 R2/2018 R2/2012 R2/2016 R2/2019 R2 | |
Linux Stable Kernel version 3.x/4.x or later; | |
Linux CentOS/RHEL 7.x or later; | |
Ubuntu 16.x or later; | |
VMware ESX/ESXi 5.x/6.x or later | |
Bus Type | PCIe v2.1(2.5GT/s & 5.0GT/s) x4 ，compatible with x8/x16 |
Data rate per port | 100MbE |
Connector | 4*100M SFP |
Protocol Support | IEEE 802.3u 100BASE-FX Ethernet IEEE 802.3az - Energy Efficient Ethernet (EEE) IEEE 802.3z IEEE 802.1Q VLANs IEEE 802.3x IEEE 1588 |
iSCSI | No |
WoL | No |
Jumbo Frames | YES |
DPDK | Yes |
PXE | Yes |
FCoE | No |
Operating Temperature | 0 ℃ to 55 ℃ (32℉ to +131℉) |
Storage Temperature | -40 ℃ to 85 ℃ (-40℉ to 185℉) |
Storage Humidity | Maximum: 90% non-condensing relative humidity at 35 ℃ |
Size(mm) | 165*120*21 |
Weight(g) | * |
LED Indicators | 100Mbps: Green Link + Green Blink |
P/N | Description |
LREC9054PF-4SFP | PCIe x4 Quad-port 100M Fiber SFP Ethernet Network Adapter (Intel Chip Based) |
